| Mechanical |
| Dimensions | 159mm x 75 mm x 14.4 mm (6.26 in x 2.95 in x 0.57 in) |
| Weight | 258g |
| Display Size | Gorilla Glass 5, 5.5-inch |
| Resolution | 1440 x 720 High Definition |
| Backlight | LED |
| Touchscreen | Multi-touch capacitive (CTP), GFF |
| Hard Keys | 5 side keys for volume up/down, right and left scan keys, power on/off |
| Environmental |
| Operating Temperature | 20°C to +50°C (-4°F to +122°F) |
| Storage Temperature | 30°C to +70°C (-22°F to 158°F) |
| Humidity | 5% to 90% (non-condensing) |
| Drop | Multiple 1.3m (4.3ft) per MIL-STD 810G drops to concrete at room temperature, Multiple 1.5m (5ft) per MIL-STD 810G drops with rubber boot concrete at room temperature |
| Tumble | 550 times at 0.5 m (1.64 ft) |
| Environmental Sealing | IP67 |
| Electrostatic Discharge (ESD) | 8 kV direct; 15 kV air |
| System Architecture |
| Processor | Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quad low-power Kryo cores 1.8 GHz |
| Memory | 3 GB RAM/32 GB Flash; 4 GB RAM/64 GB Flash; 6 GB RAM/128 GB Flash |
| Operating System | Android 11, and upgradeable to Android 13 |
| Storage Expansion | MicroSD (up to 128 GB) |
| Rear Camera | 13-megapixel color camera |
| Front Camera | 5-megapixel color camera |
| PC Interface | USB 2.0 with Type-C interface |
| Interface Ports | 2 pin bottom connection |
| Battery | Li-Ion, 3.8 V, 4,500 mAh, removable |
| Real-Time Clock (RTC) | 10 min backup via super-cap |
| Charging Time | Less than 3.5 hours |
| Scan Engine | Honeywell S0703 Slim Imager (1D/2D barcode symbologies); Non-imager version (optional) |
| LED | Battery Status Indicator: red/green/blue; Scan Indication: red/green |
| Sensors | Acceleration sensor, light sensor, and proximity sensor |
| Localization & Language | Worldwide English |
| Wireless Connectivity |
| WLAN | IEEE 802.11 a/b/g/n/ac |
| Additional WLAN Features | 802.11 d/e/h/i/k/ r/u/w /v, 1X1 MU-MIMO |
| WLAN Security | OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise) |
| WLAN Supported EAP | TLS, PEAP, TTLS, PWD, LEAP |
| Bluetooth | Bluetooth Class 5.1 |
| WWAN Radio | GSM/EDGE: Bands 2, 3, 5, 8; UMTS/HSPA+: Bands 1, 2, 4, 5, 6, 8, 9, 19; FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 12,13,17,19,20,25,26,28,30,66; TDD-LTE: Bands 38, 39, 40, 41 |
| NFC | Integrated Near Field Communication |
